Materiál | Aluminium |
Rám | T-Tronik Performer 140mm Carbon front triangle, rear alutriangle, 1.5 tapered HT, seatpost diam. 31,6mm, seatclamp diam. 34.9mm, PM 180mm, thru axle 12x148mm,internal cable routing inside DT, sizes 3 |
Vidlica | Fox 38 Float 29 Factory, e-MTB + version, 160mm travel,Fit4 3 Pos. lever w/micro adjuster, Kashima upper tubes,Rebound, Air spring pressure, 1.5 tapered HT, Kabolt15x110mm BOOST axle, 44mm rake |
Prehadzovačka | Shimano XTR RD-M9100SGS Shadow+ Design 12sp, topnormal, direct attachment, Max 10-51T |
Radenie | Shimano XT SL- M8100R 12sp |
Kľuky | Shimano FC-EM600 Alu crank 165mm, 24mm axle w/custom chainguide for 30-38T |
Kazeta | Shimano CS-M7100-12, 12sp, 10-51T |
Riadidlá | Tec Cursus rise, double butted AL7050, width 780mm,diam.35mm, rise 20mm, backsweep 9° |
Predstavec | Tec Cursus, 0°, 1.1/8 , diam. 35mm, ext: 50mm |
Sedlovka | Fox Transfer Factory, diam 31,6mm, travel: 100mm-15 ,125mm-17 , 150mm-19/21 |
Plášte | Kenda Hellkat 29x2.6, 60tpi EMC, DTC compound, 66-622 folding type |
Kolesá | DT Swiss H1700 Spline 29 30mm, thru axle front15x110mm, rear 12x148mm, Shimano 12sp Microsplinebody, TL-ready rim w/tubeless band and valve, CenterLock |
Brzdy | Shimano BL-M8120, 4 pistons brakes, resin pad,w/203mm front & rear adaptor |
Reťaz | Shimano CN-M7100, 12sp |
Stredové zloženie | Included w/motor unit |
Gripy | T-One Rock T-GP34 single lock grip , TPR, plastic innerbody, aluminium clamp |
Motor | Shimano EP8 motor Unit W/DU-EP800 Drive Unit, 34T Chainring, Speed Sensor W/630WH Integrated battery |
Hlavové zloženie | Fsa NO.77R 1.5 /ICR SB |
Brzdové kotúče | Shimano front RT-MT800 & rear RT-EM810 with magnetfor speed sensor, diam. 203mm front & rear, Center Lock |
Sedlo | Fox Float DPS Factory, Trunnion 185/50, LV, EVOL, 3position Lever, lower hardware 8x24,88mm,Fi'zi:k Alpaca Terra, S alloy rail, 249x145mm |
