Materiál | Karbón |
Rám | Nitron 29 full carbon monocoque, 1.5 tapered HT, BB92, seatpost diam. 27,2mm, HDM FD, PM 160mm carbon dropout 12x148mm BOOST Thru axle, internal cable routing, sizes 15-17-19-21 |
Vidlica | Rock Shox SID SL 29 , damper Rush RL, Debon Air 100mm w/Tall oneLoc remote left, 1.5 alu HT, 15X110mm Maxle Stealth, 32mm stanchions, magnesium lowers, PM 160mm disc mount, 44mm offset |
Prehadzovačka | Shimano XT RD-M8100-SGS Shadow Design + 12sp |
Radenie | Shimano SLX 1x12sp |
Kľuky | Shimano XT FC-M8100-1, 32T, 52mm chainline, crank length: 170mm-15 , 175mm-17/21 |
Kazeta | Shimano CS-M7100-12, 10-51T |
Riadidlá | Velomann Flat top DB Alloy 6061-T6, width 720mm, diam. 31,8mm, 9° backsweep |
Predstavec | Velomann, 3D forged alloy 6061 +/-7°, 1,1/8 x diam.31.8mm, ext: 70mm-15'', 80mm-17 , 90mm-19/21 |
Sedlovka | Velomann, AL6061 shaft with forged head, lenght 350mm-15'' and 400mm for 17,19,21 , diam.27.2mm, 0mm seatback |
Plášte | Kenda Booster Pro 29x2.20 |
Kolesá | Velomann KOM light i25 29 622x25 |
Brzdy | Shimano M6100 |
Reťaz | Shimano CN-M7100 12sp |
Stredové zloženie | Shimano Pressfit (41x92) |
Zadný náboj | Shimano FH-MT510-B |
Frame | T-One Rock T-GP34 |
Hlavové zloženie | Fsa Orbit C-40 |
Brzdové kotúče | Shimano SM-RT54 CL 180mm & 160mm, Center Lock |
Sedlo | Velomann 1285URN, manganese rail, lenght 277mm x width 144mm |
Sada radenia | Shimano XT |
Počet prevodov | 1x12 |
Zdvih odpruženia | 80-120 mm |
